Monoblock Pumpset Testing

MONOBLOCK PUMPSET TESTING
PUMPS & MOTORS


(NABL Accreditation Certificate No. TC-5538 )

Tests

TEST STANDARD RANGE
Marking Plate IS 9079 Qualitative Test
Direction of RotationDirection of Rotation Qualitative Test
Design Features Qualitative Test
General Requirements 0.75 to 15kW
Pump Performance Test 1m to 200 m
1 Ips to 50 Ip
0.01 Ato 50A
0.75 to 15kW
Stator Resistance per phase at 34°C 10 ma to 1000
No Load Test 1 to 415 V AC
0.01 to 50A
0.75 to 15 kW
45 Hz to 66 Hz
1450 to 3000 rpm
Reduced Voltage Running up Test 1 to 415 V AC
1450 to 3000rpm
Locked Rotor Test 1 to 440 V AC
0.01 to 50A
0.75 to 75 kW
Temperature Rise Test at Rated Voltage 0.01 to 50A
1 to 1000°c
Temperature Rise Test at Reduced Voltage 0.01 to 50 A
1 to 1000°c/td>
Insulation Resistance Test Up to 50G 0
High Voltage Test 0.1 to 5 kV AC /DC

Click here for Scope of Accreditation and then click on TC-5538

Click here for Testing Charges

Contact:

Mr. M.K.CHARATE Assistant Director(Flow lab) E-mail : flow@idemi.org Phone No : 022-24050301/02/03/04 ext 218 Mobile No: 9969455600
