Environmental Testing

ENVIRONMENTAL TESTING


(NABL Accreditation Certificate No. TC-5538)

Test

Tests Standard
Cold Test
-60 °C to Ambient
IEC/EN 60068-2-1, IS 9000 (Part 2/sec | to IV)
JSS 55555
Dry Heat Test
Ambient to 200 °C
IEC/EN 60068-2-2, IS 9000 (Part 3/sec | to V)
IS5155505
Change of Temperature test
-60 °C to 180 °C, Rate of change: 1 °C
IEC/EN 60068-2-14, IS 9000 (Part XIV)
JSS 55555
Damp Heat (Steady state) Test
20 % to 98 %,@ 30 °C to 85 °C
IEC/EN 60068-2-78, IS 9000 (Part 4)
JSS105555
Damp Heat (Cyclic) Test
20 % to 98 %,@ 30 ©C to 85 °C
IEC/EN 60068-2-30, IS 9000 (Part 5/Sec 1 & 2)
JSSi55555
Vibration Test/ Random Vibration Test
5 to 2800Hz, 0 to 51 mm, up to 70 'g'
IEC/EN 60068-2-6, IS9000(Part 8)
IEC/EN 60068-2-64, JSS 55555
Shock Test
Upto 50 'g'
IEC/EN 60068-2-27, IS9000(Part 7/S ec 1)
Sesmic Test
5 Hz -35 Hz
IES/EN 60068-3-3
Degree of protection (Ingress protection) Test
IP 10 - 68
IEC/EN 60529, IS/IEC 60529

Click here for Scope of Accreditation and then click on TC-5538

Click here for Testing Charges

Contact:

Mr. C.M.Patil Assistant Director(Testing lab) E-mail : etl@idemi.org Phone No : 022-24050301/02/03/04 ext 235 Mobile No: 9324350952 | 9372330934 (Lab Mobile)
